دیتاشیت TPS5450QDDARQ1
مشخصات دیتاشیت
| نام دیتاشیت |
TPS5450-Q1
|
| حجم فایل |
1895.964
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
33
|
مشخصات
-
RoHS:
true
-
Category:
Power Supply Chip/DC-DC Converters
-
Datasheet:
Texas Instruments TPS5450QDDARQ1
-
Package:
SOP-8-EP
-
Manufacturer:
Texas Instruments
-
Topology:
Buck
-
Part Status:
Active
-
Current - Output:
5A
-
Package / Case:
8-PowerSOIC (0.154", 3.90mm Width)
-
Base Part Number:
TPS545
-
Synchronous Rectifier:
No
-
Series:
Automotive, AEC-Q100, SWIFT™
-
Number of Outputs:
1
-
Voltage - Input (Min):
5.5V
-
Voltage - Output (Min/Fixed):
1.221V
-
Voltage - Output (Max):
32.04V
-
Mounting Type:
Surface Mount
-
Frequency - Switching:
500kHz
-
Packaging:
Digi-Reel®
-
Function:
Step-Down
-
Output Type:
Adjustable
-
Output Configuration:
Positive
-
Supplier Device Package:
8-SO PowerPad
-
Operating Temperature:
-40°C ~ 125°C (TJ)
-
Voltage - Input (Max):
36V
-
detail:
Buck Switching Regulator IC Positive Adjustable 1.221V 1 Output 5A 8-PowerSOIC (0.154", 3.90mm Width)
