دیتاشیت UCC28950PWR

مشخصات دیتاشیت

دانلود دیتاشیت UCC28950	UCC28950 Datasheet

Mounting Type: Surface Mount
Synchronous Rectifier: Yes
Control Features: Dead Time Control, Enable, Frequency Control, Soft Start
Packaging: Cut Tape (CT)
Output Phases: 1
Clock Sync: Yes
Function: Step-Up/Step-Down
Output Type: Transistor Driver
Supplier Device Package: 24-TSSOP
Operating Temperature: -40°C ~ 125°C (TJ)
Topology: Full-Bridge
Part Status: Active
Package / Case: 24-TSSOP (0.173", 4.40mm Width)
Number of Outputs: 6
Serial Interfaces: -
Voltage - Supply (Vcc/Vdd): 8V ~ 17V
Frequency - Switching: 50kHz ~ 1MHz
Base Part Number: UCC289
Duty Cycle (Max): 95%
Series: -
Manufacturer: Texas Instruments
Output Configuration: Positive
detail: Full-Bridge Regulator Positive Output Step-Up/Step-Down DC-DC Controller IC 24-TSSOP
