- دیتاشیت LMZ12,4yyy Generic 8D Report
دیتاشیت LMZ12,4yyy Generic 8D Report
مشخصات دیتاشیت
| نام دیتاشیت | LMZ12,4yyy Generic 8D Report |
|---|---|
| حجم فایل | 182.951 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 5 |
LMZ12,4yyy Generic 8D Report |
دانلود دیتاشیت |
|---|
سایر مستندات
LMZ1,2yyy Design Summary 9 pages
LMZ21701 Datasheet 41 pages
مشخصات فنی
- Type: Non-Isolated PoL Module
- Efficiency: 95%
- Voltage - Output 2: -
- Mounting Type: Surface Mount
- Package / Case: 8-SMD Module
- Series: SIMPLE SWITCHER® Nano
- Number of Outputs: 1
- Voltage - Input (Min): 3V
- Part Status: Active
- Base Part Number: LMZ2170
- Current - Output (Max): 1A
- Control Features: Enable, Active High
- Packaging: Cut Tape (CT)
- Manufacturer: Texas Instruments
- Voltage - Output 3: -
- Features: OCP, OTP, SCP, UVLO
- Voltage - Output 1: 0.9 ~ 6V
- Size / Dimension: 0.14" L x 0.14" W x 0.07" H (3.5mm x 3.5mm x 1.8mm)
- Operating Temperature: -40°C ~ 125°C
- Voltage - Input (Max): 17V
- Applications: ITE (Commercial)
- detail: Non-Isolated PoL Module DC DC Converter 1 Output 0.9 ~ 6V 1A 3V - 17V Input
