دیتاشیت LM22676MRE-5.0/NOPB
مشخصات دیتاشیت
| نام دیتاشیت | LM22676 Datasheet |
|---|---|
| حجم فایل | 2298.557 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 33 |
دانلود دیتاشیت LM22676 Datasheet |
LM22676 Datasheet Datasheet |
|---|
مشخصات
- RoHS: true
- Category: Power Supply Chip/DC-DC Converters
- Function: Step-down type
- Topology: Step-down
- Datasheet: Texas Instruments LM22676MRE-5.0/NOPB
- Output Type: Fixed
- Input Voltage: 4.5V~42V
- Output Voltage: 5V
- Number of Outputs: 1
- Switching Frequency: 500kHz
- Output Current (Max): 3A
- Operating Temperature: -40°C~+125°C@(TJ)
- Synchronous Rectification: NO
- Package: SOP-8
- Manufacturer: Texas Instruments
- Part Status: Active
- Current - Output: 3A
- Package / Case: 8-PowerSOIC (0.154", 3.90mm Width)
- Base Part Number: LM22676
- Synchronous Rectifier: No
- Series: SIMPLE SWITCHER®
- Voltage - Input (Min): 4.5V
- Voltage - Output (Min/Fixed): 5V
- Voltage - Output (Max): -
- Mounting Type: Surface Mount
- Frequency - Switching: 500kHz
- Packaging: Cut Tape (CT)
- Output Configuration: Positive
- Supplier Device Package: 8-SO PowerPad
- Voltage - Input (Max): 42V
- detail: Buck Switching Regulator IC Positive Fixed 5V 1 Output 3A 8-PowerSOIC (0.154", 3.90mm Width)
