LD39130SPUR دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
LD39130SPUR
|
|
حجم فایل
|
70.575
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
33
|
مشخصات فنی
-
RoHS:
true
-
Category:
Power Supply Chip/Linear Voltage Regulators (LDO)
-
Datasheet:
STMicroelectronics LD39130SPUR
-
Output Type:
Adjustable
-
Output Current:
300mA
-
Output Voltage:
0.8V~5.2V
-
Dropout Voltage:
0.3V@(300mA)
-
Output Polarity:
positive
-
Number of Outputs:
1
-
Maximum Input Voltage:
5.5V
-
Operating Temperature:
-40°C~+125°C
-
Quiescent Current (Ground Current):
45uA
-
Package:
DFN-6(1.2x1.3)
-
Manufacturer:
STMicroelectronics
-
Series:
-
-
Packaging:
Cut Tape (CT)
-
Part Status:
Active
-
Output Configuration:
Positive
-
Number of Regulators:
1
-
Voltage - Input (Max):
5.5V
-
Voltage - Output (Min/Fixed):
0.8V
-
Voltage - Output (Max):
5.2V
-
Voltage Dropout (Max):
0.3V @ 300mA (Typ)
-
Current - Output:
300mA
-
Current - Quiescent (Iq):
45µA
-
PSRR:
70dB ~ 65dB (1kHz ~ 10kHz)
-
Control Features:
Enable
-
Protection Features:
Over Current, Over Temperature, Soft Start
-
Mounting Type:
Surface Mount
-
Package / Case:
6-XFDFN
-
Supplier Device Package:
6-DFN (1.2x1.3)
-
Base Part Number:
LD39130
-
detail:
Linear Voltage Regulator IC 1 Output 300mA 6-DFN (1.2x1.3)
