LDK220 Datasheet Datasheet

LDK220 Datasheet

Datasheet specifications

Datasheet's name LDK220 Datasheet
File size 956.139 KB
File type pdf
Number of pages 27

Download Datasheet LDK220 Datasheet

Download Datasheet

Other documentations

LDK220M36R 28 pages

Technical specifications

  • RoHS: true
  • Category: Power Supply Chip/Linear Voltage Regulators (LDO)
  • Datasheet: STMicroelectronics LDK220M-R
  • Output Type: Adjustable
  • Output Current: 200mA
  • Dropout Voltage: 0.35V@(200mA)
  • Output Polarity: positive
  • Number of Outputs: 1
  • Maximum Input Voltage: 13.2V
  • Operating Temperature: -40°C~+125°C
  • Quiescent Current (Ground Current): 90uA
  • Package: SOT-23-5
  • Manufacturer: STMicroelectronics
  • Series: -
  • Packaging: Cut Tape (CT)
  • Part Status: Active
  • Output Configuration: Positive
  • Number of Regulators: 1
  • Voltage - Input (Max): 13.2V
  • Voltage - Output (Min/Fixed): -
  • Voltage - Output (Max): -
  • Voltage Dropout (Max): 0.35V @ 200mA
  • Current - Output: 200mA
  • Current - Quiescent (Iq): 90µA
  • Current - Supply (Max): 100µA
  • PSRR: 60dB ~ 45dB (120Hz ~ 10kHz)
  • Control Features: Enable
  • Protection Features: Over Current, Over Temperature
  • Mounting Type: Surface Mount
  • Package / Case: SC-74A, SOT-753
  • Supplier Device Package: SOT-23-5
  • Base Part Number: LDK220
  • detail: Linear Voltage Regulator IC 1 Output 200mA SOT-23-5
