LM350AT/NOPB 数据手册
其他文档
LM150, 350 21 pages
技术规格
- RoHS: true
- Category: Power Supply Chip/Linear Voltage Regulators (LDO)
- Datasheet: Texas Instruments LM350AT/NOPB
- Output Type: Adjustable
- Output Current: 3A
- Output Voltage: 1.25V~33V
- Output Polarity: positive
- Number of Outputs: 1
- Maximum Input Voltage: 35V
- Operating Temperature: -40°C~+125°C
- Package: TO-220
- Manufacturer: Texas Instruments
- Part Status: Active
- Current - Output: 3A
- Series: -
- Package / Case: TO-220-3
- Voltage - Output (Min/Fixed): 1.25V
- Control Features: -
- Number of Regulators: 1
- Mounting Type: Through Hole
- Voltage - Output (Max): 33V
- Base Part Number: LM350
- Protection Features: Over Current, Over Temperature, Short Circuit
- PSRR: 86dB ~ 65dB (120Hz)
- Voltage Dropout (Max): -
- Packaging: Tube
- Output Configuration: Positive
- Supplier Device Package: TO-220-3
- Voltage - Input (Max): 35V
- detail: Linear Voltage Regulator IC 1 Output 3A TO-220-3
