STTH15L06G-TR دیتاشیت

STTH15L06G-TR

مشخصات دیتاشیت

نام دیتاشیت STTH15L06G-TR
حجم فایل 43.933 کیلوبایت
نوع فایل pdf
تعداد صفحات 10

مشاهده دیتاشیت STTH15L06G-TR

دانلود دیتاشیت

سایر مستندات

STTH15L06 10 pages

مشخصات فنی

  • RoHS: true
  • Category: Diodes/Diodes - General Purpose
  • Datasheet: STMicroelectronics STTH15L06G-TR
  • Diode Configuration: -
  • Reverse Voltage (Vr): 600V
  • Forward Voltage (Vf@If): 1.15V@15A
  • Reverse Leakage Current: 15uA@600V
  • Average Rectified Current (Io): 20A
  • Package: D2PAK
  • Manufacturer: STMicroelectronics
  • Series: -
  • Packaging: Cut Tape (CT)
  • Part Status: Active
  • Diode Type: Standard
  • Voltage - DC Reverse (Vr) (Max): 600V
  • Current - Average Rectified (Io): 20A
  • Voltage - Forward (Vf) (Max) @ If: 1.55V @ 15A
  • Speed: Fast Recovery =< 500ns, > 200mA (Io)
  • Reverse Recovery Time (trr): 85ns
  • Current - Reverse Leakage @ Vr: 15µA @ 600V
  • Capacitance @ Vr, F: -
  • Mounting Type: Surface Mount
  • Package / Case: TO-263-3, D²Pak (2 Leads + Tab), TO-263AB
  • Supplier Device Package: D2PAK
  • Operating Temperature - Junction: 175°C (Max)
  • Base Part Number: STTH15L06
  • detail: Diode Standard 600V 20A Surface Mount D2PAK
