- دیتاشیت LP3856ESX-ADJ/NOPB
LP3856ESX-ADJ/NOPB دیتاشیت
مشخصات دیتاشیت
| نام دیتاشیت | LP3856ESX-ADJ/NOPB |
|---|---|
| حجم فایل | 83.313 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 23 |
دانلود دیتاشیت LP3856ESX-ADJ/NOPB |
دانلود دیتاشیت |
|---|
سایر مستندات
LP3856-ADJ 22 pages
مشخصات فنی
- RoHS: true
- Category: Power Supply Chip/Linear Voltage Regulators (LDO)
- Datasheet: Texas Instruments LP3856ESX-ADJ/NOPB
- Output Type: Adjustable
- Output Current: 3A
- Output Voltage: 1.23V~6.5V
- Dropout Voltage: 0.6V@(3A)
- Output Polarity: positive
- Number of Outputs: 1
- Maximum Input Voltage: 7V
- Operating Temperature: -40°C~+125°C
- Quiescent Current (Ground Current): 4mA
- Package: TO-263-5
- Manufacturer: Texas Instruments
- Control Features: Enable
- Base Part Number: LP3856
- Package / Case: TO-263-6, D²Pak (5 Leads + Tab), TO-263BA
- Current - Supply (Max): 10mA
- Part Status: Obsolete
- Current - Output: 3A
- PSRR: 73dB ~ 57dB (120Hz)
- Series: -
- Voltage - Output (Min/Fixed): 1.23V
- Mounting Type: Surface Mount
- Number of Regulators: 1
- Current - Quiescent (Iq): 4mA
- Output Configuration: Positive
- Voltage Dropout (Max): 0.6V @ 3A
- Supplier Device Package: DDPAK/TO-263-5
- Protection Features: Over Current, Over Temperature, Short Circuit
- Voltage - Input (Max): 7V
- Packaging: Cut Tape (CT)
- Voltage - Output (Max): 6.5V
- detail: Linear Voltage Regulator IC 1 Output 3A DDPAK/TO-263-5
