VNH7100BAS Datasheet دیتاشیت

VNH7100BAS Datasheet

مشخصات دیتاشیت

نام دیتاشیت VNH7100BAS Datasheet
حجم فایل 1291.899 کیلوبایت
نوع فایل pdf
تعداد صفحات 39

مشاهده دیتاشیت VNH7100BAS Datasheet

دانلود دیتاشیت

سایر مستندات

VNH7100BASTR 39 pages

مشخصات فنی

  • RoHS: true
  • Type: Brush DC Motor
  • Category: Power Supply Chip/Motor Driver ICs
  • Datasheet: STMicroelectronics VNH7100BASTR
  • Interface: PWM
  • Output Current: 15A
  • Supply Voltage: 4V~28V
  • Operating Temperature: -40°C~+150°C@(Tj)
  • Package: SOP-16
  • Manufacturer: STMicroelectronics
  • Series: Automotive, AEC-Q100, VIPOWER™
  • Packaging: Cut Tape (CT)
  • Part Status: Active
  • Motor Type - Stepper: -
  • Motor Type - AC, DC: Brushed DC
  • Function: Driver - Fully Integrated, Control and Power Stage
  • Output Configuration: Half Bridge (2)
  • Technology: Power MOSFET
  • Step Resolution: -
  • Applications: Automotive
  • Current - Output: 15A
  • Voltage - Supply: 4V ~ 28V
  • Voltage - Load: 4V ~ 28V
  • Mounting Type: Surface Mount
  • Package / Case: 16-SOIC (0.154", 3.90mm Width)
  • Supplier Device Package: 16-SO
  • Base Part Number: VNH7100
  • detail: Motor Driver Power MOSFET PWM 16-SO
