دیتاشیت LM2588SX-ADJ/NOPB
مشخصات دیتاشیت
| نام دیتاشیت | LM2588 |
|---|---|
| حجم فایل | 2272.325 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 38 |
دانلود دیتاشیت LM2588 |
LM2588 Datasheet |
|---|
مشخصات
- Package / Case: TO-263-8, D²Pak (7 Leads + Tab), TO-263CA
- Function: Step-Up, Step-Up/Step-Down
- Output Configuration: Positive
- Topology: Boost, Flyback, Forward Converter
- Base Part Number: LM2588
- Packaging: Cut Tape (CT)
- Operating Temperature: -40°C ~ 125°C (TJ)
- Frequency - Switching: 100kHz ~ 200kHz
- Supplier Device Package: DDPAK/TO-263-7
- Part Status: Obsolete
- Current - Output: 5A (Switch)
- Number of Outputs: 1
- Series: SIMPLE SWITCHER®
- Manufacturer: Texas Instruments
- Voltage - Input (Max): 40V
- Synchronous Rectifier: No
- Voltage - Output (Min/Fixed): 1.23V
- Voltage - Input (Min): 4V
- Mounting Type: Surface Mount
- Voltage - Output (Max): 60V
- Output Type: Adjustable
- detail: Boost, Flyback, Forward Converter Switching Regulator IC Positive Adjustable 1.23V 1 Output 5A (Switch) TO-263-8, D²Pak (7 Leads + Tab), TO-263CA
