LMZ30606 Datasheet دیتاشیت

مشخصات دیتاشیت

مشاهده دیتاشیت LMZ30606 Datasheet	دانلود دیتاشیت

RoHS: true
Category: Power Supply Chip/Power Modules
Function: -
Datasheet: Texas Instruments LMZ30606RKGT
Output Channel: 1
Output Voltage: 0.8V~3.6V
Conversion Type: DC-DC
Input Voltage(DC): 2.95V~6V
Output Current (Max): 6A
Conversion Efficiency: 96%
Package: B1QFN-39
Manufacturer: Texas Instruments
Type: Non-Isolated PoL Module
Control Features: Enable, Active High
Packaging: Cut Tape (CT)
Mounting Type: Surface Mount
Voltage - Output 3: -
Supplier Device Package: 39-B1QFN (11x9)
Voltage - Output 1: 0.8 ~ 3.6V
Operating Temperature: -40°C ~ 85°C
Applications: ITE (Commercial)
Size / Dimension: 0.44" L x 0.36" W x 0.11" H (11.2mm x 9.2mm x 2.9mm)
Voltage - Output 2: -
Package / Case: 39-BQFN Module
Efficiency: 96%
Voltage - Input (Min): 2.95V
Base Part Number: LMZ3060
Part Status: Active
Series: SIMPLE SWITCHER®
Current - Output (Max): 6A
Features: OCP, OTP, UVLO
Number of Outputs: 1
Voltage - Input (Max): 6V
detail: Non-Isolated PoL Module DC DC Converter 1 Output 0.8 ~ 3.6V 6A 2.95V - 6V Input
