TPS84320RUQR دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
TPS84320RUQR
|
|
حجم فایل
|
106.75
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
34
|
مشخصات فنی
-
RoHS:
true
-
Category:
Power Supply Chip/Power Modules
-
Function:
-
-
Datasheet:
Texas Instruments TPS84320RUQR
-
Output Channel:
1
-
Output Voltage:
0.8V~5.5V
-
Conversion Type:
DC-DC
-
Input Voltage(DC):
4.5V~14.5V
-
Output Current (Max):
3A
-
Conversion Efficiency:
95%
-
Package:
B1QFN-47
-
Manufacturer:
Texas Instruments
-
Type:
Non-Isolated PoL Module
-
Control Features:
Enable, Active High
-
Packaging:
Cut Tape (CT)
-
Mounting Type:
Surface Mount
-
Voltage - Output 3:
-
-
Supplier Device Package:
47-B1QFN (15x9)
-
Voltage - Output 1:
0.8 ~ 5.5V
-
Operating Temperature:
-40°C ~ 85°C
-
Applications:
ITE (Commercial)
-
Size / Dimension:
0.59" L x 0.35" W x 0.11" H (15.0mm x 9.0mm x 2.8mm)
-
Voltage - Output 2:
-
-
Package / Case:
47-BQFN Module
-
Efficiency:
95%
-
Voltage - Input (Min):
4.5V
-
Base Part Number:
TPS843
-
Part Status:
Active
-
Series:
-
-
Current - Output (Max):
3A
-
Features:
OCP, OTP, UVLO
-
Number of Outputs:
1
-
Voltage - Input (Max):
14.5V
-
detail:
Non-Isolated PoL Module DC DC Converter 1 Output 0.8 ~ 5.5V 3A 4.5V - 14.5V Input
