- BTW69-200
BTW69-200RG Datasheet
Datasheet specifications
| Datasheet's name | BTW69-200 |
|---|---|
| File size | 348.895 KB |
| File type | |
| Number of pages | 5 |
Download Datasheet BTW69-200 |
Download Datasheet |
|---|
Other documentations
No other documentation was found!
Technical specifications
- Manufacturer: STMicroelectronics
- Series: -
- Packaging: Tube
- Part Status: Active
- Voltage - Off State: 200V
- Voltage - Gate Trigger (Vgt) (Max): 1.5V
- Current - Gate Trigger (Igt) (Max): 80mA
- Voltage - On State (Vtm) (Max): 1.9V
- Current - On State (It (AV)) (Max): 32A
- Current - On State (It (RMS)) (Max): 50A
- Current - Hold (Ih) (Max): 150mA
- Current - Off State (Max): 10µA
- Current - Non Rep. Surge 50, 60Hz (Itsm): 580A, 610A
- SCR Type: Standard Recovery
- Operating Temperature: -40°C ~ 125°C
- Mounting Type: Through Hole
- Package / Case: TOP-3
- Supplier Device Package: TOP3
- Base Part Number: BTW69
- detail: SCR 200V 50A Standard Recovery Through Hole TOP3
