دیتاشیت TPS546C20ARVFT

مشخصات دیتاشیت

دانلود دیتاشیت TPS546C20A Datasheet	TPS546C20A Datasheet Datasheet

RoHS: true
Category: Power Supply Chip/DC-DC Converters
Datasheet: Texas Instruments TPS546C20ARVFT
Package: LQFN-CLIP-40-EP(5x7)
Manufacturer: Texas Instruments
Topology: Buck
Part Status: Active
Current - Output: 35A
Package / Case: 40-PowerLFQFN
Base Part Number: TPS546
Synchronous Rectifier: Yes
Series: -
Number of Outputs: 1
Voltage - Input (Min): 4.5V
Voltage - Output (Min/Fixed): 0.35V
Voltage - Output (Max): 5.5V
Mounting Type: Surface Mount
Frequency - Switching: 200kHz ~ 1MHz
Packaging: Cut Tape (CT)
Function: Step-Down
Output Type: Adjustable
Output Configuration: Positive
Supplier Device Package: 40-LQFN-CLIP (7x5)
Operating Temperature: -40°C ~ 125°C (TJ)
Voltage - Input (Max): 18V
detail: Buck Switching Regulator IC Positive Adjustable 0.35V 1 Output 35A 40-PowerLFQFN
