STTH30R02DJF-TR دیتاشیت

STTH30R02DJF-TR

مشخصات دیتاشیت

نام دیتاشیت STTH30R02DJF-TR
حجم فایل 46.192 کیلوبایت
نوع فایل pdf
تعداد صفحات 9

مشاهده دیتاشیت STTH30R02DJF-TR

دانلود دیتاشیت

سایر مستندات

STTH30R02DJF 9 pages

مشخصات فنی

  • RoHS: true
  • Category: Diodes/Diodes - Fast Recovery Rectifiers
  • Datasheet: STMicroelectronics STTH30R02DJF-TR
  • Diode Configuration: Single
  • Reverse Voltage (Vr): 200V
  • Operating Temperature: +175°C@(Tj)
  • Forward Voltage (Vf@If): 1V@30A
  • Reverse Leakage Current: 10uA@200V
  • Reverse Recovery Time (trr): 38ns
  • Average Rectified Current (Io): 30A
  • Package: Power-FLAT(5x6)
  • Manufacturer: STMicroelectronics
  • Series: -
  • Packaging: Cut Tape (CT)
  • Part Status: Active
  • Diode Type: Standard
  • Voltage - DC Reverse (Vr) (Max): 200V
  • Current - Average Rectified (Io): 30A
  • Voltage - Forward (Vf) (Max) @ If: 1.15V @ 30A
  • Speed: Fast Recovery =< 500ns, > 200mA (Io)
  • Current - Reverse Leakage @ Vr: 10µA @ 200V
  • Capacitance @ Vr, F: -
  • Mounting Type: Surface Mount
  • Package / Case: 8-PowerVDFN
  • Supplier Device Package: PowerFlat™ (5x6)
  • Operating Temperature - Junction: 175°C (Max)
  • Base Part Number: STTH30
  • detail: Diode Standard 200V 30A Surface Mount PowerFlat™ (5x6)
