CC1020RSST 数据手册
其他文档
CC1020 95 pages
CC1020 Errata 7 pages
技术规格
- RoHS: true
- Category: Radio Frequency Chip/Antenna/RF Transceiver ICs
- Datasheet: Texas Instruments CC1020RSST
- Interface: SPI,UART
- Applications: General-purpose ISM<1GHz
- Frequency Range: 402MHz~470MHz;804MHz~960MHz
- Receive Current: 19.9mA
- Operating Voltage: 2.3V~3.6V
- Operating Temperature: -40°C~+85°C
- Current Of Transmitting: 12.3mA
- Package: QFN-32-EP(7x7)
- Manufacturer: Texas Instruments
- GPIO: 1
- Mounting Type: Surface Mount
- Current - Transmitting: 12.3mA ~ 27.1mA
- Packaging: Cut Tape (CT)
- Type: TxRx Only
- Sensitivity: -118dBm
- Base Part Number: CC1020
- Voltage - Supply: 2.3V ~ 3.6V
- Memory Size: -
- Protocol: -
- Supplier Device Package: 32-QFN (7x7)
- Part Status: Active
- Current - Receiving: 19.9mA
- Modulation: FSK, GFSK, OOK
- Package / Case: 32-VQFN Exposed Pad
- Serial Interfaces: SPI, UART
- Power - Output: 10dBm
- Frequency: 402MHz ~ 470MHz, 804MHz ~ 960MHz
- Data Rate (Max): 153.6kBaud
- Series: -
- RF Family/Standard: General ISM < 1GHz
- detail: IC RF TxRx Only General ISM < 1GHz 402MHz ~ 470MHz, 804MHz ~ 960MHz 32-VQFN Exposed Pad
