LM53603AQPWPTQ1 دیتاشیت

مشخصات دیتاشیت

دانلود دیتاشیت LM53603AQPWPTQ1	دانلود دیتاشیت

RoHS: true
Category: Power Supply Chip/DC-DC Converters
Function: Step-down type
Topology: Step-down
Datasheet: Texas Instruments LM53603AQPWPTQ1
Output Type: Adjustable
Input Voltage: 3.9V~36V
Output Voltage: 3.3V~6V
Number of Outputs: 1
Switching Frequency: 2.1MHz
Output Current (Max): 3A
Operating Temperature: -40°C~+125°C@(TJ)
Synchronous Rectification: Yes
Package: TSSOP-16
Manufacturer: Texas Instruments
Part Status: Active
Current - Output: 3A
Package / Case: 16-PowerTSSOP (0.173", 4.40mm Width)
Base Part Number: LM536
Synchronous Rectifier: Yes
Series: Automotive, AEC-Q100
Voltage - Input (Min): 3.9V
Voltage - Output (Min/Fixed): 3.3V
Voltage - Output (Max): 6V
Mounting Type: Surface Mount
Frequency - Switching: 2.1MHz
Packaging: Cut Tape (CT)
Output Configuration: Positive
Supplier Device Package: 16-HTSSOP
Voltage - Input (Max): 36V
detail: Buck Switching Regulator IC Positive Adjustable 3.3V 1 Output 3A 16-PowerTSSOP (0.173", 4.40mm Width)
