OPA656 Datasheet

OPA656

Datasheet specifications

Datasheet's name OPA656
File size 1555.516 KB
File type pdf
Number of pages 35

Download Datasheet OPA656

Download Datasheet

Other documentations

OPA656UG4 36 pages

Technical specifications

  • RoHS: true
  • Category: Operational Amplifier/Comparator/Operational Amplifier
  • Datasheet: Texas Instruments OPA656NB/250
  • -3db Bandwidth: 500MHz
  • Output Current: 70mA
  • Number of Circuits: 1
  • Operating Temperature: -40°C~+85°C
  • Current - Input Bias(Ib): 1pA
  • Gain Bandwidth Product(GBP): 230MHz
  • Package: SOT-23-5
  • Manufacturer: Texas Instruments
  • Part Status: Active
  • Current - Supply: 14mA
  • Mounting Type: Surface Mount
  • Package / Case: SC-74A, SOT-753
  • Amplifier Type: Voltage Feedback
  • Series: -
  • Base Part Number: OPA656
  • Voltage - Input Offset: 100µV
  • Current - Input Bias: 1pA
  • Voltage - Supply, Single/Dual (±): 8V ~ 12V, ±4V ~ 6V
  • Packaging: Cut Tape (CT)
  • Output Type: -
  • Supplier Device Package: SOT-23-5
  • Gain Bandwidth Product: 230MHz
  • Slew Rate: 295V/µs
  • Current - Output / Channel: 70mA
  • detail: Voltage Feedback Amplifier 1 Circuit SOT-23-5
