STL15DN4F5 دیتاشیت

مشخصات دیتاشیت

مشاهده دیتاشیت STL15DN4F5	دانلود دیتاشیت

مستندات دیگری یافت نشد!

Manufacturer: STMicroelectronics
Series: Automotive, AEC-Q101, STripFET™ V
Packaging: Cut Tape (CT)
Part Status: Active
FET Type: 2 N-Channel (Dual)
FET Feature: Logic Level Gate
Drain to Source Voltage (Vdss): 40V
Current - Continuous Drain (Id) @ 25°C: 60A
Rds On (Max) @ Id, Vgs: 9mOhm @ 7.5A, 10V
Vgs(th) (Max) @ Id: 4V @ 250µA
Gate Charge (Qg) (Max) @ Vgs: 25nC @ 10V
Input Capacitance (Ciss) (Max) @ Vds: 1550pF @ 25V
Power - Max: 60W
Operating Temperature: -55°C ~ 175°C (TJ)
Mounting Type: Surface Mount
Package / Case: 8-PowerVDFN
Supplier Device Package: PowerFlat™ (5x6)
Base Part Number: STL15
detail: Mosfet Array 2 N-Channel (Dual) 40V 60A 60W Surface Mount PowerFlat™ (5x6)
