دیتاشیت LP3853ES-3.3/NOPB
مشخصات دیتاشیت
| نام دیتاشیت | LP3853, LP3856 |
|---|---|
| حجم فایل | 2280.236 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 25 |
دانلود دیتاشیت LP3853, LP3856 |
LP3853, LP3856 Datasheet |
|---|
مشخصات
- RoHS: true
- Category: Power Supply Chip/Linear Voltage Regulators (LDO)
- Datasheet: Texas Instruments LP3853ES-3.3/NOPB
- Package: TO-263-5
- Manufacturer: Texas Instruments
- Mounting Type: Surface Mount
- Current - Supply (Max): 10mA
- Control Features: Enable
- Packaging: Tube
- Voltage - Output (Max): -
- Voltage - Output (Min/Fixed): 3.3V
- Protection Features: Over Current, Over Temperature, Short Circuit
- Output Type: Fixed
- Supplier Device Package: DDPAK/TO-263-5
- Operating Temperature: -40°C ~ 125°C
- Current - Quiescent (Iq): 4mA
- Part Status: Active
- Current - Output: 3A
- Series: -
- Number of Regulators: 1
- PSRR: 73dB ~ 57dB (120Hz)
- Base Part Number: LP3853
- Voltage Dropout (Max): 0.6V @ 3A
- Package / Case: TO-263-6, D²Pak (5 Leads + Tab), TO-263BA
- Output Configuration: Positive
- Voltage - Input (Max): 7V
- detail: Linear Voltage Regulator IC 1 Output 3A DDPAK/TO-263-5
