دیتاشیت REF5025MDTEP
مشخصات دیتاشیت
| نام دیتاشیت |
REF50 Series
|
| حجم فایل |
1860.173
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
30
|
مشخصات
-
RoHS:
true
-
Category:
Power Supply Chip/Voltage References
-
Datasheet:
Texas Instruments REF5025MDTEP
-
Tolerance:
±0.05%
-
Output Type:
Fixed
-
Input Voltage:
2.7V~18V
-
Output Current:
10mA
-
Output Voltage:
2.5V
-
Reference Type:
series connection
-
Supply Current:
1.25mA
-
Noise - 10Hz to 10kHz:
-
-
Operating Temperature:
-55°C~+125°C@(Ta)
-
Noise - 1/10Hz to 10Hz:
7.5uVp-p
-
Temperature Coefficient:
6.5ppm/°C
-
Package:
SOP-8
-
Manufacturer:
Texas Instruments
-
Part Status:
Active
-
Current - Supply:
1.25mA
-
Current - Output:
10mA
-
Series:
-
-
Package / Case:
8-SOIC (0.154", 3.90mm Width)
-
Voltage - Output (Min/Fixed):
2.5V
-
Base Part Number:
REF502
-
Mounting Type:
Surface Mount
-
Noise - 0.1Hz to 10Hz:
7.5µVp-p
-
Voltage - Input:
2.7V ~ 18V
-
Packaging:
Cut Tape (CT)
-
Supplier Device Package:
8-SOIC
-
detail:
Series Voltage Reference IC ±0.05% 8-SOIC
