BAT46 Series دیتاشیت

BAT46 Series

مشخصات دیتاشیت

نام دیتاشیت BAT46 Series
حجم فایل 158.233 کیلوبایت
نوع فایل pdf
تعداد صفحات 11

مشاهده دیتاشیت BAT46 Series

دانلود دیتاشیت

سایر مستندات

BAT46ZFILM 11 pages

مشخصات فنی

  • RoHS: true
  • Category: Diodes/Schottky Barrier Diodes (SBD)
  • Datasheet: STMicroelectronics BAT46AWFILM
  • Diode Configuration: 1 Pair Common Anode
  • Reverse Voltage (Vr): 100V
  • Forward Voltage (Vf@If): 1V@250mA
  • Reverse Leakage Current (Ir): 5uA@75V
  • Average Rectified Current (Io): 150mA
  • Package: SC-70
  • Manufacturer: STMicroelectronics
  • Series: -
  • Packaging: Cut Tape (CT)
  • Part Status: Active
  • Diode Type: Schottky
  • Voltage - DC Reverse (Vr) (Max): 100V
  • Current - Average Rectified (Io) (per Diode): 150mA (DC)
  • Voltage - Forward (Vf) (Max) @ If: 450mV @ 10mA
  • Speed: Small Signal =< 200mA (Io), Any Speed
  • Current - Reverse Leakage @ Vr: 5µA @ 75V
  • Operating Temperature - Junction: 150°C (Max)
  • Mounting Type: Surface Mount
  • Package / Case: SC-70, SOT-323
  • Supplier Device Package: SOT-323
  • Base Part Number: BAT46
  • detail: Diode Array 1 Pair Common Anode Schottky 100V 150mA (DC) Surface Mount SC-70, SOT-323
