دیتاشیت PTH08000WAH

مشخصات دیتاشیت

دانلود دیتاشیت PTH08000W Series	PTH08000W Series Datasheet

RoHS: true
Category: Power Supply Chip/Power Modules
Datasheet: Texas Instruments PTH08000WAH
Output Channel: 1
Output Voltage: 0.9V~5.5V
Input Voltage(DC): 4.5V~14V
Output Current (Max): 2.25A
Conversion Efficiency: 93.5%
Package: DIP-6
Manufacturer: Texas Instruments
Type: Non-Isolated PoL Module
Efficiency: 93.5%
Voltage - Output 2: -
Mounting Type: Through Hole
Package / Case: 6-DIP Module
Series: PTH08000W
Number of Outputs: 1
Voltage - Input (Min): 4.5V
Part Status: Active
Base Part Number: PTH08
Current - Output (Max): 2.25A
Packaging: Tray
Voltage - Output 3: -
Features: -
Voltage - Output 1: 0.9 ~ 5.5V
Size / Dimension: 0.75" L x 0.50" W x 0.34" H (19.1mm x 12.7mm x 8.6mm)
Operating Temperature: -40°C ~ 85°C
Voltage - Input (Max): 14V
Applications: ITE (Commercial)
detail: Non-Isolated PoL Module DC DC Converter 1 Output 0.9 ~ 5.5V 2.25A 4.5V - 14V Input
