دیتاشیت ESDAXLC6-1MY2

ESDAXLC6-1MY2

مشخصات دیتاشیت

نام دیتاشیت ESDAXLC6-1MY2
حجم فایل 337.581 کیلوبایت
نوع فایل pdf
تعداد صفحات 12

دانلود دیتاشیت ESDAXLC6-1MY2

ESDAXLC6-1MY2 Datasheet

مشخصات

  • RoHS: true
  • Category: TVS/Fuse/Board Level Protection/ESD Protection Devices
  • Datasheet: STMicroelectronics ESDAXLC6-1MY2
  • Number of Lines: 1
  • Clamping Voltage@Ipp: 6V
  • Operating Temperature: -40°C~+125°C@(Tj)
  • Breakdown Voltage (VBR): 6V
  • Peak Pulse Power(Ppp)@8/20us: 12W
  • Junction Capacitance(Cj)@1MHz: 0.35pF@200MHz~3GHz
  • Peak Pulse Current(Ipp)@8/20us: -
  • Reverse Stand-Off Voltage (Vrwm): 3V
  • Package: SOD-882
  • Manufacturer: STMicroelectronics
  • Series: ESDA, TRANSIL™
  • Packaging: Cut Tape (CT)
  • Part Status: Active
  • Type: Zener
  • Unidirectional Channels: 1
  • Voltage - Reverse Standoff (Typ): 3V
  • Voltage - Breakdown (Min): 6V
  • Voltage - Clamping (Max) @ Ipp: -
  • Current - Peak Pulse (10/1000µs): -
  • Power - Peak Pulse: 12W
  • Power Line Protection: No
  • Applications: General Purpose
  • Capacitance @ Frequency: 0.35pF @ 200MHz ~ 3GHz
  • Mounting Type: Surface Mount
  • Package / Case: SOD-882
  • Supplier Device Package: SOD-882
  • Base Part Number: ESDAXLC6
  • detail: Clamp Ipp Tvs Diode Surface Mount SOD-882
