TL1431ACZT دیتاشیت
مشخصات دیتاشیت
| نام دیتاشیت | TL1431ACZT |
|---|---|
| حجم فایل | 239.707 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 16 |
دانلود دیتاشیت TL1431ACZT |
دانلود دیتاشیت |
|---|
سایر مستندات
TL1431 27 pages
TL1431AIZT 27 pages
مشخصات فنی
- RoHS: true
- Category: Power Supply Chip/Voltage References
- Datasheet: STMicroelectronics TL1431ACZT
- Tolerance: ±0.25%
- Output Type: Adjustable
- Input Voltage: -
- Output Current: 100mA
- Output Voltage: 2.5V~36V
- Reference Type: parallel connection
- Supply Current: -
- Dynamic Impedance: 0.2Ω
- Noise - 10Hz to 10kHz: -
- Operating Temperature: -20°C~+70°C@(Ta)
- Noise - 1/10Hz to 10Hz: -
- Temperature Coefficient: 90ppm/°C
- Minimum Cathode Current for Regulation: 0.6mA
- Package: TO-92
- Manufacturer: STMicroelectronics
- Series: -
- Packaging: Cut Tape (CT)
- Part Status: Active
- Voltage - Output (Min/Fixed): 2.5V
- Voltage - Output (Max): 36V
- Current - Output: 100mA
- Noise - 0.1Hz to 10Hz: -
- Voltage - Input: -
- Current - Supply: -
- Current - Cathode: 600µA
- Mounting Type: Through Hole
- Package / Case: TO-226-2, TO-92-2 (TO-226AC)
- Supplier Device Package: TO-92-3
- Base Part Number: TL1431
- detail: Shunt Voltage Reference IC 36V ±0.25% TO-92-3
