دیتاشیت EMIF04-EAR02M8

EMIF04-EAR02M8

مشخصات دیتاشیت

نام دیتاشیت EMIF04-EAR02M8
حجم فایل 441.373 کیلوبایت
نوع فایل pdf
تعداد صفحات 12

دانلود دیتاشیت EMIF04-EAR02M8

EMIF04-EAR02M8 Datasheet

مشخصات

  • Manufacturer: STMicroelectronics
  • Series: EMIF
  • Packaging: Cut Tape (CT)
  • Part Status: Active
  • Type: Low Pass
  • Filter Order: 2nd, 3rd
  • Technology: LC (Pi), RC (Pi)
  • Number of Channels: 4
  • Center / Cutoff Frequency: 60MHz, 70MHz (Cutoff)
  • Attenuation Value: -30dB @ 900MHz
  • Resistance - Channel (Ohms): -
  • Current: 50mA
  • Values: R = 68Ohms, C = 76pF, 105pF, L = 1.5nH
  • ESD Protection: Yes
  • Operating Temperature: -30°C ~ 125°C
  • Applications: Audio
  • Voltage - Rated: -
  • Mounting Type: Surface Mount
  • Package / Case: 8-UFDFN Exposed Pad
  • Size / Dimension: 0.067" L x 0.059" W (1.70mm x 1.50mm)
  • Height: 0.026" (0.65mm)
  • Base Part Number: EMIF04
  • detail: LC (Pi), RC (Pi) EMI Filter 2nd, 3rd Order Low Pass 4 Channel R = 68Ohms, C = 76pF, 105pF, L = 1.5nH 50mA 8-UFDFN Exposed Pad
