DCP01B Series دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
DCP01B Series
|
|
حجم فایل
|
1209.496
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
31
|
مشخصات فنی
-
RoHS:
true
-
Category:
Power Supply Chip/DC-DC Converters
-
Datasheet:
Texas Instruments DCP010515DBP-U
-
Package:
SOP-7-2.54mm
-
Manufacturer:
Texas Instruments
-
Applications:
ITE (Commercial)
-
Mounting Type:
Through Hole
-
Size / Dimension:
0.78" L x 0.33" W x 0.21" H (19.7mm x 8.3mm x 5.3mm)
-
Efficiency:
85%
-
Operating Temperature:
-40°C ~ 100°C
-
Packaging:
Tube
-
Type:
Isolated Module
-
Voltage - Output 2:
-15V
-
Part Status:
Active
-
Supplier Device Package:
7-PDIP
-
Voltage - Output 1:
15V
-
Number of Outputs:
2
-
Voltage - Input (Min):
4.5V
-
Control Features:
Enable, Active High
-
Voltage - Input (Max):
5.5V
-
Current - Output (Max):
33mA, 33mA
-
Power (Watts):
1W
-
Package / Case:
14-DIP (0.300", 7.62mm), 7 Leads
-
Series:
DCP01B (1W)
-
Base Part Number:
DCP0105
-
Features:
OTP, SCP
-
Voltage - Isolation:
1kV
-
Voltage - Output 3:
-
-
detail:
Isolated Module DC DC Converter 2 Output 15V -15V 33mA, 33mA 4.5V - 5.5V Input
