STU7LN80K5 Datasheet دیتاشیت
مشخصات دیتاشیت
| نام دیتاشیت | STU7LN80K5 Datasheet |
|---|---|
| حجم فایل | 403.751 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 12 |
دانلود دیتاشیت STU7LN80K5 Datasheet |
دانلود دیتاشیت |
|---|
سایر مستندات
مشخصات فنی
- Manufacturer: STMicroelectronics
- Series: MDmesh™
- Packaging: Tube
- Part Status: Active
- FET Type: N-Channel
- Technology: MOSFET (Metal Oxide)
- Drain to Source Voltage (Vdss): 800V
- Current - Continuous Drain (Id) @ 25°C: 5A (Tc)
- Drive Voltage (Max Rds On, Min Rds On): 10V
- Rds On (Max) @ Id, Vgs: 1.15Ohm @ 2.5A, 10V
- Vgs(th) (Max) @ Id: 5V @ 100µA
- Gate Charge (Qg) (Max) @ Vgs: 12nC @ 10V
- Vgs (Max): ±30V
- Input Capacitance (Ciss) (Max) @ Vds: 270pF @ 100V
- FET Feature: -
- Power Dissipation (Max): 85W (Tc)
- Operating Temperature: -55°C ~ 150°C (TJ)
- Mounting Type: Through Hole
- Supplier Device Package: IPAK (TO-251)
- Package / Case: TO-251-3 Short Leads, IPak, TO-251AA
- Base Part Number: STU7L
- detail: N-Channel 800V 5A (Tc) 85W (Tc) Through Hole IPAK (TO-251)
