مشاهده دیتاشیت LM5180-Q1 Datasheet	دانلود دیتاشیت

مستندات دیگری یافت نشد!

Topology: Flyback
Part Status: Active
Current - Output: -
Package / Case: 8-WDFN Exposed Pad
Base Part Number: LM5180
Synchronous Rectifier: No
Series: Automotive, AEC-Q100
Number of Outputs: 1
Voltage - Input (Min): 4.5V
Voltage - Output (Min/Fixed): 5V
Voltage - Output (Max): -
Mounting Type: Surface Mount, Wettable Flank
Frequency - Switching: 12kHz ~ 350kHz
Manufacturer: Texas Instruments
Packaging: Cut Tape (CT)
Function: Step-Up/Step-Down
Output Type: Fixed
Output Configuration: Positive and Negative
Supplier Device Package: 8-WSON (4x4)
Operating Temperature: -40°C ~ 150°C (TJ)
Voltage - Input (Max): 65V
detail: Flyback Switching Regulator IC Positive and Negative Fixed 5V 1 Output 8-WDFN Exposed Pad
