BULD741T4 دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
BULD741T4
|
|
حجم فایل
|
55.316
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
11
|
مشخصات فنی
-
RoHS:
true
-
Category:
Triode/MOS Tube/Transistor/Bipolar Transistors - BJT
-
Datasheet:
STMicroelectronics BULD741T4
-
Transistor Type:
NPN
-
Operating Temperature:
+150°C@(Tj)
-
Collector Current (Ic):
2.5A
-
Power Dissipation (Pd):
30W
-
Transition Frequency (fT):
-
-
DC Current Gain (hFE@Ic,Vce):
25@450mA,3V
-
Collector Cut-Off Current (Icbo):
250uA
-
Collector-Emitter Breakdown Voltage (Vceo):
400V
-
Collector-Emitter Saturation Voltage (VCE(sat)@Ic,Ib):
500mV@2A,600mA
-
Package:
TO-252-2(DPAK)
-
Manufacturer:
STMicroelectronics
-
Series:
-
-
Packaging:
Cut Tape (CT)
-
Part Status:
Active
-
Current - Collector (Ic) (Max):
2.5A
-
Voltage - Collector Emitter Breakdown (Max):
400V
-
Vce Saturation (Max) @ Ib, Ic:
1.5V @ 600mA, 2A
-
Current - Collector Cutoff (Max):
250µA
-
DC Current Gain (hFE) (Min) @ Ic, Vce:
25 @ 450mA, 3V
-
Power - Max:
30W
-
Frequency - Transition:
-
-
Mounting Type:
Surface Mount
-
Package / Case:
TO-252-3, DPak (2 Leads + Tab), SC-63
-
Supplier Device Package:
DPAK
-
Base Part Number:
BULD741
-
detail:
Bipolar (BJT) Transistor NPN 400V 2.5A 30W Surface Mount DPAK
