STTH1003SB-TR دیتاشیت

STTH1003SB-TR

مشخصات دیتاشیت

نام دیتاشیت STTH1003SB-TR
حجم فایل 43.5 کیلوبایت
نوع فایل pdf
تعداد صفحات 10

مشاهده دیتاشیت STTH1003SB-TR

دانلود دیتاشیت

سایر مستندات

STTH1003S 9 pages

مشخصات فنی

  • RoHS: true
  • Category: Diodes/High Effic Rectifier
  • Datasheet: STMicroelectronics STTH1003SB-TR
  • Diode Configuration: Single
  • Reverse Voltage (Vr): 300V
  • Operating Temperature: +175°C@(Tj)
  • Forward Voltage (Vf@If): 1.3V@10A
  • Reverse Recovery Time (trr): 28ns
  • Reverse Leakage Current (Ir): 10uA@300V
  • Average Rectified Current (Io): 10A
  • Package: TO-252
  • Manufacturer: STMicroelectronics
  • Series: ECOPACK®2
  • Packaging: Cut Tape (CT)
  • Part Status: Active
  • Diode Type: Standard
  • Voltage - DC Reverse (Vr) (Max): 300V
  • Current - Average Rectified (Io): 10A
  • Voltage - Forward (Vf) (Max) @ If: 1.3V @ 10A
  • Speed: Fast Recovery =< 500ns, > 200mA (Io)
  • Current - Reverse Leakage @ Vr: 10µA @ 300V
  • Capacitance @ Vr, F: -
  • Mounting Type: Surface Mount
  • Package / Case: TO-252-3, DPak (2 Leads + Tab), SC-63
  • Supplier Device Package: DPAK
  • Operating Temperature - Junction: 175°C (Max)
  • Base Part Number: STTH10
  • detail: Diode Standard 300V 10A Surface Mount DPAK
