دیتاشیت XL0840
مشخصات دیتاشیت
| نام دیتاشیت |
XL0840
|
| حجم فایل |
415.033
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
8
|
مشخصات
-
RoHS:
true
-
Category:
Triode/MOS Tube/Transistor/TRIACs
-
SCR Type:
门极灵敏型
-
Datasheet:
STMicroelectronics XL0840
-
Holding Current (Ih):
5mA
-
Operating Temperature:
-40°C~+125°C
-
Gate Trigger Current(Igt):
200uA
-
Gate Trigger Voltage (Vgt):
800mV
-
RMS On-State Current(It (rms)):
800mA
-
Peak Forward On?State Voltage (Vtm):
1.95V
-
Peak Repetitive Off?State Voltage (Vdrm):
400V
-
Package:
TO-92
-
Manufacturer:
STMicroelectronics
-
Series:
-
-
Packaging:
Bulk
-
Part Status:
Active
-
Voltage - Off State:
400V
-
Voltage - Gate Trigger (Vgt) (Max):
800mV
-
Current - Gate Trigger (Igt) (Max):
200µA
-
Voltage - On State (Vtm) (Max):
1.95V
-
Current - On State (It (AV)) (Max):
500mA
-
Current - On State (It (RMS)) (Max):
800mA
-
Current - Hold (Ih) (Max):
5mA
-
Current - Off State (Max):
1µA
-
Current - Non Rep. Surge 50, 60Hz (Itsm):
7A, 8A
-
Mounting Type:
Through Hole
-
Package / Case:
TO-226-3, TO-92-3 (TO-226AA)
-
Supplier Device Package:
TO-92-3
-
Base Part Number:
XL0840
-
detail:
SCR 400V 800mA Sensitive Gate Through Hole TO-92-3
