STPS10170CB-TR دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
STPS10170CB-TR
|
|
حجم فایل
|
45.117
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
10
|
مشخصات فنی
-
RoHS:
true
-
Category:
Diodes/Schottky Barrier Diodes (SBD)
-
Datasheet:
STMicroelectronics STPS10170CB-TR
-
Diode Configuration:
Dual Common Cathode
-
Reverse Voltage (Vr):
170V
-
Forward Voltage (Vf@If):
920mV@5A
-
Reverse Leakage Current (Ir):
10uA@170V
-
Average Rectified Current (Io):
5A
-
Package:
TO-252
-
Manufacturer:
STMicroelectronics
-
Series:
-
-
Packaging:
Cut Tape (CT)
-
Part Status:
Active
-
Diode Type:
Schottky
-
Voltage - DC Reverse (Vr) (Max):
170V
-
Current - Average Rectified (Io) (per Diode):
5A
-
Voltage - Forward (Vf) (Max) @ If:
920mV @ 5A
-
Speed:
Fast Recovery =< 500ns, > 200mA (Io)
-
Current - Reverse Leakage @ Vr:
10µA @ 170V
-
Operating Temperature - Junction:
175°C (Max)
-
Mounting Type:
Surface Mount
-
Package / Case:
TO-252-3, DPak (2 Leads + Tab), SC-63
-
Supplier Device Package:
DPAK
-
Base Part Number:
STPS10170
-
detail:
Diode Array 1 Pair Common Cathode Schottky 170V 5A Surface Mount TO-252-3, DPak (2 Leads + Tab), SC-63
