L5150CJTR دیتاشیت

L5150CJTR

مشخصات دیتاشیت

نام دیتاشیت L5150CJTR
حجم فایل 75.96 کیلوبایت
نوع فایل pdf
تعداد صفحات 34

مشاهده دیتاشیت L5150CJTR

دانلود دیتاشیت

سایر مستندات

L5150C(J,S) 34 pages

مشخصات فنی

  • RoHS: true
  • Category: Power Supply Chip/Linear Voltage Regulators (LDO)
  • Datasheet: STMicroelectronics L5150CJTR
  • Output Type: Fixed
  • Output Current: 150mA
  • Output Voltage: 5V
  • Dropout Voltage: 500mV@(150mA)
  • Output Polarity: Positive
  • Number of Outputs: 1
  • Maximum Input Voltage: 40V
  • Operating Temperature: -40°C~+150°C
  • Quiescent Current (Ground Current): 80uA
  • Power Supply Rejection Ratio (PSRR): 48dB@(100Hz)
  • Package: PowerSSO-12
  • Manufacturer: STMicroelectronics
  • Series: -
  • Packaging: Tube
  • Part Status: Active
  • Output Configuration: Positive
  • Number of Regulators: 1
  • Voltage - Input (Max): 40V
  • Voltage - Output (Min/Fixed): 5V
  • Voltage - Output (Max): -
  • Voltage Dropout (Max): 0.5V @ 150mA
  • Current - Output: 150mA
  • Current - Quiescent (Iq): 80µA
  • Current - Supply (Max): 4.2mA
  • PSRR: 48dB (100Hz)
  • Control Features: Reset
  • Protection Features: Over Temperature, Short Circuit
  • Mounting Type: Surface Mount
  • Package / Case: PowerSSO-12
  • Supplier Device Package: PowerSSO-12
  • Base Part Number: L5150
  • detail: Linear Voltage Regulator IC 1 Output 150mA PowerSSO-12
