دیتاشیت TN1215-600B-TR

TN1215, TYNx12 Datasheet

مشخصات دیتاشیت

نام دیتاشیت TN1215, TYNx12 Datasheet
حجم فایل 352.428 کیلوبایت
نوع فایل pdf
تعداد صفحات 17

دانلود دیتاشیت TN1215, TYNx12 Datasheet

TN1215, TYNx12 Datasheet Datasheet

مشخصات

  • Manufacturer: STMicroelectronics
  • Series: -
  • Packaging: Cut Tape (CT)
  • Part Status: Active
  • Voltage - Off State: 600V
  • Voltage - Gate Trigger (Vgt) (Max): 1.3V
  • Current - Gate Trigger (Igt) (Max): 15mA
  • Voltage - On State (Vtm) (Max): 1.6V
  • Current - On State (It (AV)) (Max): 8A
  • Current - On State (It (RMS)) (Max): 12A
  • Current - Hold (Ih) (Max): 40mA
  • Current - Off State (Max): 5µA
  • Current - Non Rep. Surge 50, 60Hz (Itsm): 115A, 110A
  • SCR Type: Standard Recovery
  • Operating Temperature: -40°C ~ 125°C
  • Mounting Type: Surface Mount
  • Package / Case: TO-252-3, DPak (2 Leads + Tab), SC-63
  • Supplier Device Package: DPAK
  • Base Part Number: TN1215
  • detail: SCR 600V 12A Standard Recovery Surface Mount DPAK
