DCP021212DP دیتاشیت
مشخصات دیتاشیت
| نام دیتاشیت | DCP021212DP |
|---|---|
| حجم فایل | 751.14 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 20 |
دانلود دیتاشیت DCP021212DP |
دانلود دیتاشیت |
|---|
سایر مستندات
DCP020503U 36 pages
DCP021212DP 18 pages
مشخصات فنی
- RoHS: true
- Category: Power Supply Chip/DC-DC Converters
- Datasheet: Texas Instruments DCP021212DP
- Package: PDIP-7
- Manufacturer: Texas Instruments
- Type: Isolated Module
- Control Features: -
- Packaging: Tube
- Mounting Type: Through Hole
- Power (Watts): 2W
- Voltage - Output 3: -
- Supplier Device Package: 7-PDIP
- Voltage - Output 1: 12V
- Operating Temperature: -40°C ~ 85°C
- Applications: ITE (Commercial)
- Size / Dimension: 0.78" L x 0.33" W x 0.21" H (19.7mm x 8.3mm x 5.3mm)
- Voltage - Output 2: -12V
- Package / Case: 14-DIP (0.300", 7.62mm), 7 Leads
- Efficiency: 88%
- Voltage - Input (Min): 10.8V
- Voltage - Isolation: 1kV
- Base Part Number: DCP0212
- Part Status: Active
- Series: DCP02 (2W)
- Current - Output (Max): 83mA, 83mA
- Features: OTP
- Number of Outputs: 2
- Voltage - Input (Max): 13.2V
- detail: Isolated Module DC DC Converter 2 Output 12V -12V 83mA, 83mA 10.8V - 13.2V Input
