دیتاشیت STTH1506TPI
مشخصات دیتاشیت
| نام دیتاشیت |
STTH1506TPI
|
| حجم فایل |
75.85
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
5
|
مشخصات
-
Manufacturer:
STMicroelectronics
-
Series:
-
-
Packaging:
Tube
-
Part Status:
Active
-
Diode Configuration:
1 Pair Series Connection
-
Diode Type:
Standard
-
Voltage - DC Reverse (Vr) (Max):
600V
-
Current - Average Rectified (Io) (per Diode):
15A
-
Voltage - Forward (Vf) (Max) @ If:
3.6V @ 15A
-
Speed:
Fast Recovery =< 500ns, > 200mA (Io)
-
Reverse Recovery Time (trr):
35ns
-
Current - Reverse Leakage @ Vr:
20µA @ 600V
-
Operating Temperature - Junction:
150°C (Max)
-
Mounting Type:
Through Hole
-
Package / Case:
TOP-3 Insulated
-
Supplier Device Package:
TOP-3I
-
Base Part Number:
STTH1506
-
detail:
Diode Array 1 Pair Series Connection Standard 600V 15A Through Hole TOP-3 Insulated
