دیتاشیت P0111MA 1AA3

P011xx Series

مشخصات دیتاشیت

نام دیتاشیت P011xx Series
حجم فایل 94.868 کیلوبایت
نوع فایل pdf
تعداد صفحات 9

دانلود دیتاشیت P011xx Series

P011xx Series Datasheet

مشخصات

  • RoHS: true
  • Category: Triode/MOS Tube/Transistor/TRIACs
  • SCR Type: 门极灵敏型
  • Datasheet: STMicroelectronics P0111MA 1AA3
  • Holding Current (Ih): 5mA
  • Operating Temperature: -40°C~+125°C
  • Gate Trigger Current(Igt): 25uA
  • Gate Trigger Voltage (Vgt): 800mV
  • RMS On-State Current(It (rms)): 800mA
  • Peak Forward On?State Voltage (Vtm): 1.95V
  • Peak Repetitive Off?State Voltage (Vdrm): 600V
  • Package: TO-92
  • Manufacturer: STMicroelectronics
  • Series: -
  • Packaging: Bulk
  • Part Status: Active
  • Voltage - Off State: 600V
  • Voltage - Gate Trigger (Vgt) (Max): 800mV
  • Current - Gate Trigger (Igt) (Max): 25µA
  • Voltage - On State (Vtm) (Max): 1.95V
  • Current - On State (It (AV)) (Max): 500mA
  • Current - On State (It (RMS)) (Max): 800mA
  • Current - Hold (Ih) (Max): 5mA
  • Current - Off State (Max): 10µA
  • Current - Non Rep. Surge 50, 60Hz (Itsm): 7A, 8A
  • Mounting Type: Through Hole
  • Package / Case: TO-226-3, TO-92-3 (TO-226AA)
  • Supplier Device Package: TO-92-3
  • Base Part Number: P0111
  • detail: SCR 600V 800mA Sensitive Gate Through Hole TO-92-3
