دیتاشیت DCR010505U/1K
مشخصات دیتاشیت
| نام دیتاشیت |
DCR01 Series
|
| حجم فایل |
822.505
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
28
|
مشخصات
-
RoHS:
true
-
Category:
Power Supply Chip/DC-DC Converters
-
Function:
-
-
Topology:
-
-
Datasheet:
Texas Instruments DCR010505U/1K
-
Input Voltage:
4.5V~5.5V
-
Output Voltage:
5V
-
Number of Outputs:
1
-
Switching Frequency:
400kHz
-
Output Current (Max):
200mA
-
Synchronous Rectification:
Yes
-
Package:
SOP-12-300mil
-
Manufacturer:
Texas Instruments
-
Type:
Isolated Module
-
Control Features:
Enable, Active High
-
Packaging:
Cut Tape (CT)
-
Mounting Type:
Surface Mount
-
Power (Watts):
1W
-
Voltage - Output 3:
-
-
Supplier Device Package:
12-SOP
-
Voltage - Output 1:
5V
-
Operating Temperature:
-40°C ~ 85°C
-
Applications:
ITE (Commercial)
-
Size / Dimension:
0.70" L x 0.41" W x 0.10" H (17.9mm x 10.3mm x 2.5mm)
-
Voltage - Output 2:
-
-
Package / Case:
28-SOIC (0.295", 7.50mm Width), 12 Leads
-
Efficiency:
-
-
Voltage - Input (Min):
4.5V
-
Voltage - Isolation:
1kV
-
Base Part Number:
DCR010505
-
Part Status:
Active
-
Series:
DCR01 (1W)
-
Current - Output (Max):
200mA
-
Features:
Remote On/Off, OTP, SCP
-
Voltage - Input (Max):
5.5V
-
detail:
Isolated Module DC DC Converter 1 Output 5V 200mA 4.5V - 5.5V Input
