دیتاشیت A5970ADTR
مشخصات دیتاشیت
| نام دیتاشیت |
A5970AD
|
| حجم فایل |
1016.368
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
42
|
مشخصات
-
RoHS:
true
-
Category:
Power Supply Chip/DC-DC Converters
-
Function:
Step-down type
-
Topology:
Step-down
-
Datasheet:
STMicroelectronics A5970ADTR
-
Output Type:
Adjustable
-
Input Voltage:
4V~36V
-
Output Voltage:
1.235V~36V
-
Number of Outputs:
1
-
Switching Frequency:
500kHz
-
Output Current (Max):
1A
-
Operating Temperature:
-40°C~+150°C@(TJ)
-
Synchronous Rectification:
NO
-
Package:
SOP-8
-
Manufacturer:
STMicroelectronics
-
Series:
Automotive, AEC-Q100
-
Packaging:
Tube
-
Part Status:
Obsolete
-
Output Configuration:
Positive
-
Voltage - Input (Min):
4V
-
Voltage - Input (Max):
36V
-
Voltage - Output (Min/Fixed):
1.235V
-
Voltage - Output (Max):
36V
-
Current - Output:
1A
-
Frequency - Switching:
500kHz
-
Synchronous Rectifier:
No
-
Mounting Type:
Surface Mount
-
Package / Case:
8-SOIC (0.154", 3.90mm Width)
-
Supplier Device Package:
8-SO
-
Base Part Number:
A5970
-
detail:
Buck Switching Regulator IC Positive Adjustable 1.235V 1 Output 1A 8-SOIC (0.154", 3.90mm Width)
