دیتاشیت TM4C129ENCPDTT3

TM4C129ENCPDT Datasheet

مشخصات دیتاشیت

نام دیتاشیت TM4C129ENCPDT Datasheet
حجم فایل 10706.492 کیلوبایت
نوع فایل pdf
تعداد صفحات 2014

دانلود دیتاشیت TM4C129ENCPDT Datasheet

TM4C129ENCPDT Datasheet Datasheet

مشخصات

  • RoHS: true
  • EEPROM: -
  • CPU Core: ARM-MSeries
  • Category: Single Chip Microcomputer/Microcontroller/Microcontroller Units (MCUs/MPUs/SOCs)
  • RAM Size: -
  • Watchdog: Yes
  • ADC (Bit): 12bit
  • DAC (Bit): -
  • Datasheet: Texas Instruments TM4C129ENCPDTT3
  • PWM (Bit): -
  • Real-Time Clock: -
  • CPU Maximum Speed: 120MHz
  • GPIO Ports Number: 90
  • Low-Voltage Detect: Yes
  • CCP Capture/Compare: -
  • Internal Comparator: -
  • Internal Oscillator: Yes
  • Peripheral/Function: PWM;WDT
  • Program Memory Type: FLASH
  • Direct Memory Access: Yes
  • Program Storage Size: 1MB
  • Universal Serial Bus: Yes
  • communication protocol: -
  • Operating Voltage Range: 2.97V~3.63V
  • Infrared Data Association: Yes
  • Operating Temperature Range: -40°C~+105°C
  • Secure Digital Input and Output: -
  • Package: TQFP-128(14x14)
  • Manufacturer: Texas Instruments
  • Mounting Type: Surface Mount
  • Connectivity: CANbus, EBI/EMI, Ethernet, I²C, IrDA, QEI, SPI, SSI, UART/USART, USB OTG
  • Packaging: Tray
  • Data Converters: A/D 20x12b
  • Number of I/O: 90
  • Core Size: 32-Bit
  • Core Processor: ARM® Cortex®-M4F
  • Supplier Device Package: 128-TQFP (14x14)
  • Operating Temperature: -40°C ~ 105°C (TA)
  • Part Status: Active
  • EEPROM Size: 6K x 8
  • Package / Case: 128-TQFP
  • Voltage - Supply (Vcc/Vdd): 2.97V ~ 3.63V
  • Program Memory Size: 1MB (1M x 8)
  • Base Part Number: TM4C
  • Speed: 120MHz
  • Series: Tiva™ C
  • Oscillator Type: Internal
  • Peripherals: Brown-out Detect/Reset, DMA, Motion Control PWM, POR, PWM, WDT
  • detail: ARM® Cortex®-M4F Tiva™ C Microcontroller IC 32-Bit 120MHz 1MB (1M x 8) FLASH 128-TQFP (14x14)
