ACS120-7ST Datasheet

ACS120-7SB/SFP/ST

Datasheet specifications

Datasheet's name ACS120-7SB/SFP/ST
File size 122.445 KB
File type pdf
Number of pages 11

Download Datasheet ACS120-7SB/SFP/ST

Download Datasheet

Other documentations

No other documentation was found!

Technical specifications

  • Manufacturer: STMicroelectronics
  • Series: ASD™
  • Packaging: Tube
  • Part Status: Active
  • Triac Type: Logic - Sensitive Gate
  • Voltage - Off State: 700V
  • Current - On State (It (RMS)) (Max): 2A
  • Voltage - Gate Trigger (Vgt) (Max): 1V
  • Current - Non Rep. Surge 50, 60Hz (Itsm): 20A, 11A
  • Current - Gate Trigger (Igt) (Max): 10mA
  • Current - Hold (Ih) (Max): 45mA
  • Configuration: Single
  • Operating Temperature: -30°C ~ 125°C (TJ)
  • Mounting Type: Through Hole
  • Package / Case: TO-220-3
  • Supplier Device Package: TO-220AB
  • Base Part Number: ACS120
  • detail: TRIAC Logic - Sensitive Gate 700V 2A Through Hole TO-220AB
