دیتاشیت TN5050H-12WY

TN5050H-12WY

مشخصات دیتاشیت

نام دیتاشیت TN5050H-12WY
حجم فایل 232.597 کیلوبایت
نوع فایل pdf
تعداد صفحات 10

دانلود دیتاشیت TN5050H-12WY

TN5050H-12WY Datasheet

مشخصات

  • Manufacturer: STMicroelectronics
  • Series: Automotive, AEC-Q101
  • Packaging: Tube
  • Part Status: Active
  • Voltage - Off State: 1.2kV
  • Voltage - Gate Trigger (Vgt) (Max): 1V
  • Current - Gate Trigger (Igt) (Max): 50mA
  • Voltage - On State (Vtm) (Max): 1.55V
  • Current - On State (It (AV)) (Max): 51A
  • Current - On State (It (RMS)) (Max): 80A
  • Current - Hold (Ih) (Max): 100mA
  • Current - Off State (Max): 5µA
  • Current - Non Rep. Surge 50, 60Hz (Itsm): 580A, 633A
  • SCR Type: Standard Recovery
  • Operating Temperature: -40°C ~ 150°C
  • Mounting Type: Through Hole
  • Package / Case: TO-247-3
  • Supplier Device Package: TO-247-3
  • Base Part Number: TN5050
  • detail: SCR 1.2kV 80A Standard Recovery Through Hole TO-247-3
