دیتاشیت LMZ10505EXTTZ/NOPB
مشخصات دیتاشیت
| نام دیتاشیت | LMZ10505EXT |
|---|---|
| حجم فایل | 4535.845 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 37 |
دانلود دیتاشیت LMZ10505EXT |
LMZ10505EXT Datasheet |
|---|
مشخصات
- RoHS: true
- Category: Power Supply Chip/Power Modules
- Datasheet: Texas Instruments LMZ10505EXTTZ/NOPB
- Package: TO-PMOD-7
- Manufacturer: Texas Instruments
- Type: Non-Isolated PoL Module
- Efficiency: 96%
- Voltage - Output 2: -
- Mounting Type: Surface Mount
- Package / Case: TO-PMOD-7, Power Module
- Series: SIMPLE SWITCHER®
- Number of Outputs: 1
- Voltage - Input (Min): 2.95V
- Part Status: Active
- Base Part Number: LMZ10505
- Current - Output (Max): 5A
- Control Features: Enable, Active High
- Packaging: Cut Tape (CT)
- Voltage - Output 3: -
- Features: UVLO
- Voltage - Output 1: 0.8 ~ 5V
- Size / Dimension: 0.40" L x 0.39" W x 0.18" H (10.2mm x 9.9mm x 4.6mm)
- Operating Temperature: -55°C ~ 125°C
- Voltage - Input (Max): 5.5V
- Applications: ITE (Commercial)
- detail: Non-Isolated PoL Module DC DC Converter 1 Output 0.8 ~ 5V 5A 2.95V - 5.5V Input
