LM140LAH-5.0 دیتاشیت

LM140LAH-5.0

مشخصات دیتاشیت

نام دیتاشیت LM140LAH-5.0
حجم فایل 104.354 کیلوبایت
نوع فایل pdf
تعداد صفحات 16

دانلود دیتاشیت LM140LAH-5.0

دانلود دیتاشیت

سایر مستندات

LM140L, LM340L Series 16 pages

مشخصات فنی

  • RoHS: true
  • Category: Power Supply Chip/Linear Voltage Regulators (LDO)
  • Datasheet: Texas Instruments LM140LAH-5.0
  • Output Current: 100mA
  • Output Voltage: 5V
  • Dropout Voltage: 2V@(1A)
  • Output Polarity: positive
  • Number of Outputs: 1
  • Maximum Input Voltage: 35V
  • Operating Temperature: -55°C~+125°C
  • Quiescent Current (Ground Current): 3mA
  • Power Supply Rejection Ratio (PSRR): 72dB@(120Hz)
  • Package: TO-39
  • Manufacturer: Texas Instruments
  • Mounting Type: Through Hole
  • Current - Supply (Max): 4.5mA
  • Control Features: -
  • Packaging: Bulk
  • Voltage - Output (Max): -
  • Voltage - Output (Min/Fixed): 5V
  • Protection Features: Over Temperature, Short Circuit
  • Output Type: Fixed
  • Supplier Device Package: TO-39-3
  • Current - Quiescent (Iq): 3mA
  • Part Status: Active
  • Current - Output: 100mA
  • Series: -
  • Number of Regulators: 1
  • PSRR: 72dB (120Hz)
  • Base Part Number: LM140
  • Voltage Dropout (Max): 2V @ 1A
  • Package / Case: TO-205AD, TO-39-3 Metal Can
  • Output Configuration: Positive
  • Voltage - Input (Max): 35V
  • detail: Linear Voltage Regulator IC 1 Output 100mA TO-39-3
