DAC7614EB دیتاشیت

DAC7614EB

مشخصات دیتاشیت

نام دیتاشیت DAC7614EB
حجم فایل 84.098 کیلوبایت
نوع فایل pdf
تعداد صفحات 18

دانلود دیتاشیت DAC7614EB

دانلود دیتاشیت

سایر مستندات

DAC7614 Datasheet 17 pages

مشخصات فنی

  • RoHS: true
  • Category: ADC/DAC/Data Conversion/Digital To Analog Converters (DACs)
  • Datasheet: Texas Instruments DAC7614EB
  • Interface: SPI
  • Resolution: 12Bit
  • Output Type: Voltage-缓冲
  • Settling Time: 10us
  • Supply Voltage: 5V
  • Integral nonlinearity: ±1LSB
  • Operating Temperature: -40°C~+85°C
  • Package: SSOP-20
  • Manufacturer: Texas Instruments
  • Part Status: Active
  • Voltage - Supply, Digital: 5V
  • Mounting Type: Surface Mount
  • Package / Case: 20-SSOP (0.209", 5.30mm Width)
  • Series: -
  • INL/DNL (LSB): ±1 (Max), ±1 (Max)
  • Differential Output: No
  • Voltage - Supply, Analog: ±5V
  • Reference Type: External
  • Data Interface: SPI
  • Base Part Number: DAC7614
  • Number of Bits: 12
  • Packaging: Tube
  • Number of D/A Converters: 4
  • Supplier Device Package: 20-SSOP
  • Architecture: R-2R
  • detail: 12 Bit Digital to Analog Converter 4 20-SSOP
