- Datasheet STM32F101x(C,D,E) Datasheet
STM32F101x(C,D,E) Datasheet Datasheet
Datasheet specifications
| Datasheet's name | STM32F101x(C,D,E) Datasheet |
|---|---|
| File size | 1900.156 KB |
| File type | |
| Number of pages | 121 |
Download Datasheet STM32F101x(C,D,E) Datasheet |
Download Datasheet |
|---|
Other documentations
STM32F101VDT6 112 pages
Technical specifications
- RoHS: true
- EEPROM: -
- CPU Core: ARM Cortex-M3
- Category: Single Chip Microcomputer/Microcontroller/Microcontroller Units (MCUs/MPUs/SOCs)
- RAM Size: 48KB
- Watchdog: Yes
- ADC (Bit): 12bit
- DAC (Bit): 12bit
- Datasheet: STMicroelectronics STM32F101VET6
- PWM (Bit): -
- Real-Time Clock: -
- CPU Maximum Speed: 36MHz
- GPIO Ports Number: 80
- Low-Voltage Detect: Yes
- CCP Capture/Compare: -
- Internal Comparator: -
- Internal Oscillator: Yes
- Peripheral/Function: DMA;PWM;On-chip temperature sensor
- Program Memory Type: FLASH
- Direct Memory Access: Yes
- Program Storage Size: 512KB
- Universal Serial Bus: -
- communication protocol: -
- Operating Voltage Range: 2V~3.6V
- Infrared Data Association: Yes
- Operating Temperature Range: -40°C~+85°C
- Secure Digital Input and Output: -
- Package: LQFP-100(14x14)
- Manufacturer: STMicroelectronics
- Series: STM32F1
- Packaging: Tray
- Part Status: Active
- Core Processor: ARM® Cortex®-M3
- Core Size: 32-Bit
- Speed: 36MHz
- Connectivity: I²C, IrDA, LINbus, SPI, UART/USART
- Peripherals: DMA, PDR, POR, PVD, PWM, Temp Sensor, WDT
- Number of I/O: 80
- Program Memory Size: 512KB (512K x 8)
- EEPROM Size: -
- Voltage - Supply (Vcc/Vdd): 2V ~ 3.6V
- Data Converters: A/D 16x12b; D/A 2x12b
- Oscillator Type: Internal
- Operating Temperature: -40°C ~ 85°C (TA)
- Mounting Type: Surface Mount
- Package / Case: 100-LQFP
- Supplier Device Package: 100-LQFP (14x14)
- Base Part Number: STM32F101
- detail: ARM® Cortex®-M3 STM32F1 Microcontroller IC 32-Bit 36MHz 512KB (512K x 8) FLASH 100-LQFP (14x14)
