STGP30M65DF2 دیتاشیت

STGP30M65DF2

مشخصات دیتاشیت

نام دیتاشیت STGP30M65DF2
حجم فایل 706.036 کیلوبایت
نوع فایل pdf
تعداد صفحات 16

دانلود دیتاشیت STGP30M65DF2

دانلود دیتاشیت

سایر مستندات

مستندات دیگری یافت نشد!

مشخصات فنی

  • Manufacturer: STMicroelectronics
  • Series: -
  • Packaging: Tube
  • Part Status: Active
  • IGBT Type: Trench Field Stop
  • Voltage - Collector Emitter Breakdown (Max): 650V
  • Current - Collector (Ic) (Max): 60A
  • Current - Collector Pulsed (Icm): 120A
  • Vce(on) (Max) @ Vge, Ic: 2V @ 15V, 30A
  • Power - Max: 258W
  • Switching Energy: 300µJ (on), 960µJ (off)
  • Input Type: Standard
  • Gate Charge: 80nC
  • Td (on/off) @ 25°C: 31.6ns/115ns
  • Test Condition: 400V, 30A, 10Ohm, 15V
  • Reverse Recovery Time (trr): 140ns
  • Operating Temperature: -55°C ~ 175°C (TJ)
  • Mounting Type: Through Hole
  • Package / Case: TO-220-3
  • Supplier Device Package: TO-220
  • Base Part Number: STGP30
  • detail: IGBT Trench Field Stop 650V 60A 258W Through Hole TO-220
