STTH810FP دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
STTH810FP
|
|
حجم فایل
|
68.206
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
11
|
مشخصات فنی
-
RoHS:
true
-
Category:
Diodes/Diodes - Fast Recovery Rectifiers
-
Datasheet:
STMicroelectronics STTH810FP
-
Diode Configuration:
Single
-
Reverse Voltage (Vr):
1kV
-
Operating Temperature:
+175°C@(Tj)
-
Forward Voltage (Vf@If):
2V@8A
-
Reverse Leakage Current:
5uA@1kV
-
Reverse Recovery Time (trr):
64ns
-
Average Rectified Current (Io):
8A
-
Package:
TO-220F-2
-
Manufacturer:
STMicroelectronics
-
Series:
-
-
Packaging:
Tube
-
Part Status:
Active
-
Diode Type:
Standard
-
Voltage - DC Reverse (Vr) (Max):
1000V
-
Current - Average Rectified (Io):
8A
-
Voltage - Forward (Vf) (Max) @ If:
2V @ 8A
-
Speed:
Fast Recovery =< 500ns, > 200mA (Io)
-
Current - Reverse Leakage @ Vr:
5µA @ 1000V
-
Capacitance @ Vr, F:
-
-
Mounting Type:
Through Hole
-
Package / Case:
TO-220-2 Full Pack, Isolated Tab
-
Supplier Device Package:
TO-220FPAC
-
Operating Temperature - Junction:
175°C (Max)
-
Base Part Number:
STTH810
-
detail:
Diode Standard 1000V 8A Through Hole TO-220FPAC
